Core Grinding Take-up Machine Ergonomic System For Wire Drawing Operations​

Brand Name : Suntech

Model Number : JJQ

Certification : ISO

Place of Origin : China,ningbo

MOQ : 1 PCS

Price : Negotiation

Payment Terms : L/C,T/T

Supply Ability : 3500 PCS/Month

Delivery Time : 3-7days

Packaging Details : Plywood Case

Name : Core grinding take-up machine

Item No. : 08192

Model : JJQ-3/S

Tractive force : 1.25-3T

Power : 3.04-6.61KW

Weight : 115-188KG

Contact Now

Core Grinding Take-up Machine Ergonomic System For Wire Drawing Operations​


1. Professional Wire Processing Performance​

  • Simultaneous grinding and take-up operation for continuous production
  • Maintains ±0.01mm diameter tolerance for precision wire
  • Processes wire speeds up to 1200m/min


​​2. Industrial-Grade Construction​

  • Heavy-duty cast iron frame with vibration damping
  • Hardened steel grinding wheels with automatic dressing
  • Corrosion-resistant components for harsh environments


​​3. Advanced Control Features​

  • PLC control system with touchscreen interface
  • Automatic diameter monitoring and adjustment
  • Real-time tension control system


​​4. Ergonomic Design Advantages​

  • Centralized control panel for easy operation
  • Quick-change grinding wheel mechanism
  • Low noise operation (<75dB)


​​5. Comprehensive Applications​

  • Ideal for processing:
    • Copper wire (0.5-6mm diameter)
    • Aluminum wire
    • Steel wire
    • Alloy wires
    • Specialty conductive wires


​​6. Low Maintenance Operation​

  • Self-lubricating bearings
  • Automated grinding wheel dressing system
  • Easy-access maintenance points


​​7. Productivity Enhancements​

  • 30% faster than traditional separate processes
  • Continuous operation capability
  • Reduces material waste by up to 15%


​​8. Production Line Ready​

  • Compact footprint for space efficiency
  • Compatible with standard wire drawing machines
  • Quick setup (under 15 minutes)


​​9. Professional Certifications​

  • Meets ISO 9001 quality standards
  • CE and UL certified
  • Recommended by wire industry experts


​​10. Long-Term Value​

  • 50,000+ hours service life
  • Reduces labor costs by 40%
  • Improves product consistency


​​11. Power Options​

  • 380V/220V AC electric motor
  • Energy-efficient servo drive systems
  • Optional frequency conversion control


​​12. Environmental Benefits​

  • Closed-loop coolant system
  • Energy recovery during braking
  • 90% recyclable materials


​​13. User-Friendly Features​

  • Automatic fault diagnosis system
  • Production data logging
  • Remote monitoring capability


​​14. Package Contents​

  • Main grinding/take-up unit
  • Set of precision grinding wheels
  • Control system with HMI
  • Operation and maintenance manual


​​15. Industry Applications​

  • Wire drawing mills
  • Cable manufacturing plants
  • Electrical component production
  • Automotive wire suppliers
  • Specialty wire producers


​​16. Performance Advantages​

  • Maintains ±1% diameter consistency
  • Processes 3x more material than manual methods
  • Adaptable to various wire alloys


​​17. Technical Innovations​

  • Patented multi-axis grinding system
  • AI-based wear compensation
  • Smart vibration damping technology


​​18. Purchase Options​

  • Available through industrial machinery suppliers
  • Custom configuration services
  • Turnkey installation available


​​19. Training Resources​

  • VR operation simulations
  • On-site operator training
  • 24/7 technical support


​​20. Quality Assurance​

  • Each unit laser-calibrated
  • 2-year warranty on critical components
  • ISO 14001 environmental certification


Item No. Model Rotation direction Gear

rotational

speed

(RPM)

Traction

speed

(M/MIN)

Tractive force(T) Power(KW) Outline(mm) Weight(KG)
08192

JJQ-3/S

9HP

Gasoline

engine


corotation I slow 9.0 11.0 1.25 4.04 900*460*660 115
Ⅱ fast 18.0 22.0 0.75
reversal reverse 8.0 10.0 No lifting
08192A

JJC-3/S

4HP

Diesel

engine

corotation I slow 10.5 13.0 1.25 2.94 940*500*660 132
Ⅱ fast 19.0 23.0 0.75
reversal reverse 9.0 11.0 No lifting
08194

JJQ-5/S

9HP

Gasoline

engine


corotation I slow 6.5 8.5 3.0 6.61 1000*720*600 155
Ⅱ fast 16.0 20.0 1.4
reversal reverse 7.0 9.0 No lifting
08193

JJQ-5/S

6.6HP

Diesel

engine

corotation I slow 8.0 10.0 3.0 4.41 1000*850*520 188
Ⅱ fast 19.0 23.0 1.4
reversal reverse 10.0 12.0 No lifting
